F5 MERV 5 Synthetic Fiber Ceiling Air Filter

The F5 MERV 5 Synthetic Fiber Ceiling Air Filter is made from fracture-resistant synthetic fiber fully dipped in water-soluble resin, with a high-density polyester cloth or net backing on the air outlet side; its layered fiber density ensures strong air permeability and even airflow distribution. Available in five models (400-650g, 22-24mm thick) with efficiency from 93.1% to 99.9%, max airflow of 900m³/h, heat resistance up to 100°C, and F-1/UL900 Class 2 flame resistance, it’s widely used in automotive painting, furniture spraying lines, dust-free workshops, HVAC systems, and other high-standard air purification and coating applications.

Cloth backing
Net backing

FREE QUOTE NOW Get Instant Quote

Leave a Message

Material

Filament hot-melt fracture-resistant synthetic fiber, fully dipped with high-quality water-soluble resin through multiple processes. Add high-density polyester cloth or net on the air outlet side.

By increasing the fiber density layer by layer, air permeability can be improved, and sufficient airflow is ensured to evenly distribute airflow in the working space.

Application

It is widely used in automobile painting equipment, furniture spraying lines, dust-free workshops, and other air-conditioning systems, as well as various purification workshops, metallurgy, and other high requirements of airpurification and surface coating applications.

Dimension and Specification

Mode	HJ-650G	HJ-600G	HJ-560G	HJ-500G
Color	White	White	White	White
Weight	650G	600G	560G	500G
Thickness	24±2mm	22±2mm	22±2mm	22±2mm
Max. Airflow	900m³/h	900m³/h	900m³/h	900m³/h
Initial Resistance	40pa	35pa	30pa	28pa
Final Resistance	450pa	450pa	450pa	450pa
Eficiency	99.90%	99.80%	99.60%	95.00%
NominalVelocit	0.25m/s	0.26m/s	0.27m/s	0.28m/s
Dust Holding Capacity	512g/m²	477g/m²	427g/m²	400g/m²
Max Temp	100°C	100°C	100°C	100°C
Filtering Grade	F5	F5	F5	F5
Flame resistance	F-1DIN53438 UL900-Class2	F-1DIN53438 UL900-Class2	F-1DIN53438 UL900-Class2	F-1DIN53438 UL900-Class2
